Volkswagen Touran Service Manual: Bonding Agent

Definition:
Bonding Agent -LLS MAX 015-, plastic
Edition 10/2012
Product Description
The Bonding Agent -LLS MAX 015- is a universal single-component bonding agent for all standard exterior plastic vehicle parts.
Properties:
Easy processing
Good adhesion properties
High elasticity
Application Instructions
Base Surface
Suitable base surfaces:
All standard plastic parts used on car exteriors (PP, EPDM, ABS, PC, PPO, PA, R-TPU, PBTP, PVC, PUR, PUR soft foam, UP-GF).

Pre-treatment of base surfaces:
The base surface must be free of separating agents.
Before cleaning plastic parts, temper them for 60 minutes at +60 ℃ to "sweat out" the separating agents.
  Clean using Antistatic Plastic Cleaner -LVM 001 001 A2- or a milder Silicone Remover, Long -LVM 020 100 A5-.
  Note
The effort needed for cleaning depends on the type and quantity of the separating agent used. We recommend using a sanding pad to help cleaning
Let the thinner evaporate (for example, air-drying overnight at room temperature or 30-40 minutes at +60℃ (140 F)).
  Bonding Agent
  Before priming, lightly clean again using Antistatic Plastic Cleaner -LVM 001 001 A2- or Silicone Remover, Long -LVM 020 100 A5- (antistatic effect).
  Bonding Agent
Processing
Application:
  Shake the can thoroughly for two minutes.
  Bonding Agent
Application type "coat"
  Apply one preliminary sealed spray application (1-2 mm).
Spraying distance:
  Maintain a distance of 20 to 25 cm.
  Bonding Agent
Ventilate: at +20 C (68 F) room temperature for 10 to 15 minutes.
  Note
If the spraying procedure is interrupted, make sure that the valve above the spray head is empty to prevent any nozzle blockage.
Sanded-through areas that are not larger than 5.0 cm can be reworked using Bonding Agent -LLS MAX 015-directly with top coat.
Further Processing
Fill with:
Elasticized two-part HS filler (for elastification, refer to the technical application instructions for the respective filler).
Can be painted over with:
Two-Part HS Top Coat
Water-based base paint and two-part HS clear coats
  Caution
For work safety, wear appropriate, personal protective equipment.
Note the safety data sheets as well as the warnings on the label of the spray nozzle.
Shake briefly again before every spray application.
Dispose of the empty spray cans as recyclable material.
Characteristics
  Bonding Agent
VOC value: 2004/42/IIB(e)(840)730 The EU limit for this product (product category IIB.e) in ready-to-use form is a maximum of 840 g/L volatile organic compounds. The VOC-value of this product in ready-to-use form is a maximum of 730 g/L.


Storage
The guaranteed shelf life of 60 months from date of manufacture. Use no later than the date indicated on the label and store in original container at +20 C (68 F).
  Bonding Agent
Storage Conditions
The prescribed storage temperature is +20 to +25 C (68 F to 77 F) )(do not to fall below +5 C (41 F)).
